Key Features
Auto/Manual Mode
Float or Level Sensor Operation
Dry Run, Overload, Phase Protection
Overload & Short Circuit Protection
LED Indications: Power ON, Pump 1 ON, Pump 2 ON, Pump Trip
Digital Volt/Amp Meter, Hooter for Low/High level
1W + 1S: One pump runs while the other is on standby
1W + 1Assist: Second pump starts when demand is high
Each pump alternates every cycle
Alternates pumps based on time intervals
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | Power Pro |
| Phase | Three Phase |
| Operating Voltage | 380 – 440V AC |
| Frequency Range | 50/60 Hz |
| Operating Current Range | Up to 16 A |
| Hp Range | 0.5 HP to 2.0 HP |
| Panel Material | CRCA sheet , Powder coated. |
| Protection Devices | MCB, OLR, Dry Run, Phase Failure |
| Panel Dimension |
Applications
- small commercial buildings
