Key Features
PLC-based control with pump rotation
Any 2 pumps run, 1 standby (auto-managed)
Overload and short circuit protection
Fault detection with buzzer/alarm
Thermal, overload, phase protection
Float/level sensor control
Energy-efficient & intelligent operation
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | Power Pro |
| Phase | Three Phase |
| Operating Voltage | 380 – 440V AC |
| Frequency Range | 50/60 Hz |
| Operating Current Range | Up to 16 A |
| Hp Range | 0.5 HP to 2.0 HP |
| Panel Material | CRCA sheet , Powder coated. |
| Protection Devices | Individual Overload & Breaker for Each Pump |
| Panel Dimension |
Applications
- Industrial plants, medium to large sumps
- Continuous operation with redundancy
