Key Features
Automatic operation based on pressure switch or sensor feedback
Ensures consistent water pressure to top floors or terrace outlets
Single or dual pump configuration (Duty/Standby or Parallel Mode)
Auto alternation logic for pump longevity and equal usage
Dry run protection with auto reset or manual reset options
LED indicators for Power ON, Pump Run, Fault, and Low Water
Manual/Auto selector switch for local control
Pressure tank interface or line pressure monitoring capability
Optional VFD control for pressure modulation and energy savings
Buzzer alarm for fault condition (dry run, overload, etc.)
Compact, wall-mountable design suitable for high-rise applications
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | Power Pro |
| Phase | Three-Phase |
| Operating Voltage | 380 – 440V AC |
| Frequency Range | 50/60 Hz |
| Pump Types Supported | Centrifugal, submersible (typical) |
| Hp Range | 0.5 HP to 5 HP |
| Panel Material | CRCA sheet , Powder coated. |
| Feedback Device | Pressure sensor or flow sensor |
| Cooling Method | Forced cooling (for >15 HP) |
| Control System | Pressure switch-based or sensor-based (VFD) |
Applications
- High-rise apartments, hotels, and commercial buildings
- Ensures sufficient pressure at upper-level fixtures
- Balances flow to terrace water outlets, flush systems, and taps
- Reduces water complaints and dry tap issues at peak hours
- Can be integrated with overhead tank level control or BMS
