Key Features
Manual/Auto selectors for individual pumps
Manual/Auto selectors for individual pumps
Sequential start/stop to avoid inrush current
Moisture detection & thermistor protection on all pumps
Programmable alarms: Overload, High Level, Dry Run,
Optional HMI touch display for monitoring & diagnostics
SCADA/BMS integration ready (optional)
3 Working + 1 Standby, 2 Working + 2 Standby, or 1 Working + 3 Assist, customizable with PLC
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | Power Pro |
| Phase | Three Phase |
| Operating Voltage | 380 – 440V AC |
| Frequency Range | 50/60 Hz |
| Operating Current Range | Up to 16 A |
| Hp Range | 0.5 HP to 2.0 HP |
| Panel Material | CRCA sheet , Powder coated. |
| Protection Devices | Individual Overload & Breaker for Each Pump |
| Panel Dimension |
Applications
- Sewage treatment plants
- Large commercial/industrial buildings
- Municipal sewage networks
