Key Features
Micro Controller based
Digital Volt & Ammeters
Fully Automatic / Semi Automatic option Manual (ON and OFF)
Auto Power On Delay Timer
Single Phase Preventer protection
Programmable Current setting
Current sensing Dry Run and Over Load protection
Dry Run Trip Restart timer
7 Segment LED Display Indication
Tank Level-Based Auto ON/OFF via Float Switches
Alternate Run Logic if One Pump Trip
Operates 2 Pumps Simultaneously by cyclic timer
Manualy Pump Selection
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | Power Pro |
| Phase | Three Phase |
| Operating Voltage | 320V TO 440V |
| Frequency Current | 50/60 Hz |
| Operating Current | 1.0 A TO 30 A |
| Hp Range | 1.0 TO 10 HP DOL , 10-20 HP Star- Delta |
| Degree Of Protection | IP42 |
| Panel Material | CRCA sheet , Powder coated. |
| Contractor Brand | L&T,BCH ,SIEMENS |
| Panel Dimension |
Applications
- Three Phase Monoblock, Openwel, Borewell Submersible & Dewatering Pumps
- Automatic Operation for Domastic & Agriculture (2 Pumps – Alternate & Parallel run)
