Key Features
Micro Controller based
Digital Volt & Ammeters
Automatic / Semi Automatic option Manual (ON and OFF)
Auto Power On Delay Timer
Single Phase Preventer protection
Programmable Current setting
Current sensing Dry Run and Over Load protection
Dry Run Trip Restart timer / Cyclic Timer (ON and OFF)
7 Segment LED Display Indication
Low/ High Voltage Cut-Off
Automaticaly Top / Bottom Tank Water Level Control
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | Power Pro |
| Phase | Three Phase |
| Operating Voltage | 320V To 440V |
| Frequency Range | 50/60 Hz |
| Operating Current | 1.0A to 30A |
| Hp Range | 10-20 HP Star-Delta |
| Degree Of Protection | IP42 |
| Panel Material | CRCA Sheet,Powder Coated |
| Contractor Brand | L&T,BCH,Siemens |
| Panel Dimension |
Applications
- Three Phase Monoblock, Openwel, Borewell Submersible & Dewatering Pumps
- Automatic Operation for Domastic & Agriculture
- Dewatering pumps
