Key Features
Dry run & overload protection
Volt & Amp meter (optional)
Runtime equalization
Float switch or sensor-based automation
Auto ON/OFF via Float Switch or Level Controller
Display: Status of all 3 pumps + alarms
3 Pumps (Any combination: 2W + 1S / 1W + 2ASSIST)
PLC controls logic based on runtime, demand, error feedback
PLC Based Only (Cyclic not suitable for 3 pumps)
Intelligent Auto-Rotation
Built-in protection & diagnostic
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | Power Pro |
| Phase | Three-Phase |
| Operating Voltage | 380-440V Ac |
| Frequency Range | 50/60 Hz |
| Operating Current | Up to 16A |
| HP Range | 0.5 Hp to 2.0 Hp |
| Panel Material | CRCA Sheet , Powder Coated |
| Timer | 24-hour RTC,Programmable |
| Panel Diemension |
Applications
- Open Well / Surface Pumps for automated overhead tank filling
- Commercial buildings Hotels,small industrial use
